TECHNICAL DATA AND STANDARD ACCESSORIES

• Movable head 45° left and 90° right
• Reduction unit in oil bath
• Adjustable blade protection clutch
• Blade holder shaft on bearings
• Double hinged pin with eccentric bush
• Adjustable stops 0° – 45° – 90°
• Quick locking double vice complete with anti-burr device
• Membrane pump for coolant
• Coolant filter
• Jet separation system to keep the blade oiled
• Sliding countervice for longitudinal cutting
• Bar support arm
• Bar stop
• Service tools
• Instruction manual and spare parts list
• 24 V low voltage installation hold-to-run head control knob
• Overall dimensions: 1475 mm x 1000 mm x 1150 mm
