TECHNICAL DATA AND STANDARD ACCESSORIES

• High-capacity band control by two-speed motor and special reducer with bronze gear tempered and ground worm screw
• Appropriately dimensioned flywheels
• Strong band guides with tight stress-raiser bearings and adjustable widia tips
• Band stretching is obtained by electro-mechanical blade tensioner with microswitch
• Accident-preventing devices on the flywheel casing, on the control handle, and on the blade
• Cutting thickness 1,2 mm
• Adjustable stop for cuts of the same size
• 0,06 kW power – driven pump for band cooling
• Pedestal with chip collection tray and removable tank for coolant
• Machine pre-arrenged to be moved on transpallet
• Operation:
  Cycle start is obtained by pressing the relevant start button. The machine performs the following operations during the cutting cycle:
  1. vice closing and activation of band motor
  2. cutting bow downstroke
  3. return of bow to initial position
  4. band motor stop
  5. vice opening.
• Possibility of manual cut
